Dynoteg 500S 2WD car dyno with drive on support rollers

Dynoteg 500S 2WD car dyno with drive on support rollers

Dynoteg 500S 2WD car dyno with eddy current brake and Sportdevices SP5 dyno electronics and software.

Max. power - Dynamic: 590 kW (800 HP)
Max. speed: 300 km/h

This dyno is suitable for chiptuning (real time mapping, before and after test), race teams, car tuners etc.

Dynoteg 500S 2WD car chassis dynamometer by Dynoteg.com

TB-ASDC500R2WD
€24,995.00 excl. VAT
Quantity

Dynoteg 500S 2WD car chassis dyno with eddy current brake

This Dynoteg 500S 2WD car dyno with eddy current brake can be used for testing cars with front or rear wheel drive. The Dynoteg 500S 2WD chassis dyno has been equiped with Sportdevices SP5 elektronics DAQ. The Sportdevices Sportdyno software is included (free updates).

The Dynoteg 500S 2WD car dyno can be used for static and dynamic testing up to 590kW (800 HP) at 300 km/h. The maximum speed on this 2WD car dyno is 300 km/h. The dyno has support rollers which will assist you to position the car on the dyno. The main rollers are locked when driving the car on the dyno.

This 2WD car dyno can be upgraded to 4WD.

The Dynoteg 500S 2WD car dyno can be installed in a pit or on top of the floor.

Free support by phone, e-mail, whatsapp and online login!

Dynoteg makes tuning easy!

Height
550mm (top chassis)
Depth
900mm
Length
3380mm (incl. cover)
Weight
1500 kg
Supply Voltage
200 - 240 VAC / 50 - 60 Hz
Max. axle load
1500kg
Max. speed
300km/h
Roller diameter
500mm
Roller width
650mm
Track width range
840-2140mm
Max. power
590kW (800HP)
Dyno electronics
Sportdevices SP5
Working principle
Eddy current brake
Possible tests
Braked acceleration test, inertia test, steady test, Step test

Download

Sportdyno 4.0.38.2

Sportdyno dyno software, version 4.0.38.2

Download (2.51MB)
